国标规格
| 钢丝 |
针尖数 |
植针式 |
|||||||||||
| (25.4mm)2 |
锡林 |
道夫 |
运输 |
工作 |
托毛 |
清扫 |
风轮 |
||||||
| 号数CWG |
直径MM |
形状 |
毛纺 |
风轮 |
植针宽MM |
||||||||
| 57.2 |
50.8 |
44.5 |
38.1 |
28.6 |
25.4 |
38.1 |
38.1 |
47.6 |
|||||
| 行×针（条纹）行×针（斜纹） |
|||||||||||||
| 26 |
0.48 |
圆 |
160 |
60 |
6×3 |
6×3 |
6×2 |
4×3 |
3×3 |
2×3 |
3×3 |
6×4 |
|
| 27 |
0.43 |
″ |
200 |
60 |
7×3 |
″ |
5×3 |
″ |
″ |
″ |
″ |
″ |
″ |
| 28 |
0.405 |
″ |
240 |
80 |
″ |
″ |
″ |
″ |
″ |
″ |
5×4 |
″ |
″ |
| 29 |
0.38 |
″ |
280 |
100 |
″ |
″ |
″ |
″ |
″ |
″ |
″ |
″ |
″ |
| 30 |
0.355 |
″ |
320 |
120 |
8×3 |
7×3 |
6×3 |
5×3 |
4×3 |
″ |
″ |
″ |
″ |
| 31 |
0.33 |
″ |
360 |
140 |
″ |
″ |
″ |
″ |
″ |
″ |
″ |
″ |
″ |
| 32 |
0.305 |
″ |
400 |
160 |
″ |
″ |
″ |
″ |
″ |
″ |
″ |
″ |
″ |
| 33 |
0.28 |
″ |
440 |
180 |
″ |
″ |
″ |
″ |
″ |
4×3 |
″ |
″ |
″ |
| 34 |
0.255 |
″ |
480 |
200 |
9×3 |
8×3 |
7×3 |
6×3 |
″ |
″ |
5×6 |
″ |
″ |
| 35 |
0.23 |
″ |
520 |
220 |
″ |
″ |
″ |
″ |
″ |
″ |
″ |
″ |
″ |
| 36 |
0.205 |
″ |
560 |
240 |
10×3 |
9×3 |
″ |
7×3 |
″ |
″ |
″ |
″ |
″ |
意大利工艺标准
|
Count No. |
Wire No. |
Points/inch |
mm Round |
|
0 |
21 |
110 |
0.810 |
|
2 |
22 |
130 |
0.710 |
|
4 |
23 |
150 |
0.630 |
|
6 |
24 |
170 |
0.580 |
|
8 |
25 |
190 |
0.530 |
|
10 |
26 |
215 |
0.480 |
|
12 |
27 |
240 |
0.430 |
|
14 |
28 |
265 |
0.405 |
|
16 |
29 |
290 |
0.380 |
|
18 |
30 |
320 |
0.355 |
|
20 |
31 |
360 |
0.330 |
|
22 |
32 |
400 |
0.305 |
|
24 |
33 |
450 |
0.280 |
|
26 |
34 |
500 |
0.255 |
|
28 |
35 |
550 |
0.230 |
|
30 |
36 |
600 |
0.205 |
日本工艺标准
底布有泡沬层或毛毡层的针布(粗梳毛纺专用)
锡林、道夫、工作辊、剥毛辊和专移辊用针布。
| 针布型号 |
32针布钢丝 |
针头数/(25.4mm)2 锡林、道夫、工作辊、 剥毛辊、转移辊针布 |
|
| 号数 (CWG) |
35 线径(mm) |
||
| 16 |
28 |
0.405 |
280 |
| 18 |
29 |
0.38 |
320 |
| 20 |
30 |
0.355 |
360 |
| 22 |
31 |
0.33 |
400 |
| 24 |
32 |
0.305 |
450 |
| 26 |
33 |
0.28 |
500 |
| 28 |
34 |
0.255 |
550 |
| 30 |
35 |
0.23 |
600 |
| 32 |
35 |
0.23 |
650 |
日本工艺标准
风轮针布
| 针布型号 |
针布钢泡沬 层针布 |
丝(CWG) 毛毡层 针布 |
针头数/(25.4mm)2 |
| 16 |
28 |
29 |
80 |
| 18 |
29 |
30 |
100 |
| 20 |
30 |
31 |
120 |
| 22 |
31 |
32 |
140 |
| 24 |
32 |
33 |
160 |
| 26 |
33 |
34 |
180 |
| 28 |
34 |
35 |
200 |
| 30 |
35 |
36 |
220 |
| 32 |
35 |
36 |
240 |
日本工艺标准
道夫清洁辊针布
针布型号 |
针布钢泡 沬层针布 |
丝(CWG) 毛毡层 针布 |
针头数/(25.4mm)2 |
16 |
- |
29 |
110 |
18 |
- |
30 |
110 |
20 |
- |
31 |
120 |
22 |
- |
32 |
120 |
24 |
32 |
33 |
130 |
26 |
33 |
34 |
130 |
28 |
34 |
35 |
140 |
30 |
35 |
36 |
140 |
32 |
- |
36 |
150 |
日本工艺标准
底布有泡沬层的针布(废纺、石棉纺专用)
锡林、道夫、工作辊、剥毛辊、转移辊、道夫清洁辊和风轮用针布
| 针布型号 |
针布钢丝 |
针头数/(25.4mm)2 |
|||
| 号数(CWG) |
线径( |
锡林、道夫、工作辊、剥毛辊、转移辊针布 |
风轮针布 |
道夫、清洁辊、针布 |
|
| 60 |
26 |
0.48 |
240 |
- |
- |
| 70 |
27 |
0.43 |
280 |
- |
- |
| 80 |
28 |
0.405 |
320 |
80 |
100 |
| 90 |
29 |
0.38 |
360 |
100 |
110 |
| 100 |
30 |
0.355 |
400 |
120 |
120 |
| 110 |
31 |
0.33 |
450 |
140 |
120 |
| 120 |
32 |
0.305 |
500 |
160 |
140 |
椭圆型、扁针系列
| Wire No. |
Points/Inch |
mm biconvex |
| 18/22 |
80 |
1.215×0.710 |
| 19/23 |
95 |
1.015×0.630 |
| 20/24 |
110 |
0.910×0.580 |
| 21/25 |
130 |
0.810×0.530 |
| 22/26 |
160 |
0.710×0.480 |
| 23/27 |
185 |
0.630×0.430 |
| 24/28 |
215 |
0.580×0.405 |
| 25/29 |
245 |
0.530×0.380 |
| 26/30 |
280 |
0.480×0.355 |
| 27/31 |
310 |
0.430×0.330 |
| 28/32 |
360 |
0.405×0.305 |
| 29/33 |
400 |
0.380×0.280 |
| 30/34 |
450 |
0.355×0.255 |
起毛系列
| 型号Type |
钢丝Wire |
针高A |
工作角X |
植针角Y |
底布 |
针数(25.4mm)2 |
日本金井型号KANAI |
用途 |
||
| 号数(CWG) |
线径Dia.(mm) |
截面 |
宽 |
|||||||
|
弯脚起毛针布Raising(bend tooth) |
||||||||||
| QR-3 |
27/31# |
0.430/.0330 |
 |
9.1 |
42° |
78° |
23 |
290 |
用于棉毛、混纺、化纤织物、大衣呢、制服呢、女工呢、毛毯等起毛，起绒工艺 |
|
| QR-4 |
28/32# |
0.450/0.305 |
9.1 |
42° |
78° |
300 |
||||
| QR-6 |
27/31# |
0.430/0.330 |
9.1 |
45° |
78° |
290 |
||||
| QR-8 |
27/31# |
0.430/0.330 |
9.1 |
42° |
83° |
290 |
||||
| QR-9 |
28/32# |
0.405/0.305 |
9.1 |
45° |
75° |
330 |
||||
| QR-10 |
27/31# |
0.430/.0330 |
9.0 |
40° |
82° |
310 |
RA-1 |
|||
| QR-11 |
27/31# |
0.430/0.330 |
9.5 |
40° |
89° |
310 |
RA-2 |
|||
| QR-12 |
28/32# |
0.405/0.305 |
9.0 |
48° |
72° |
330 |
RA-3 |
|||
| QR-13 |
33# |
0.28 |
 |
9.5 |
50° |
82° |
310 |
用于羊绒布料起绒 |
||
| QR-21 |
33# |
0.28 |
10.5 |
65° |
76° |
230 |
RA-22 |
经编起毛 |
||
| QR-22 |
31# |
0.33 |
10.5 |
45° |
80° |
300 |
RA-23 |
|||
| QR-23 |
33# |
0.28 |
9.8 |
80° |
72° |
52 |
190 |
马海毛起绒 |
||
直脚拉绒、刷帚
起毛针布规格系列表 Series of Specifications of Raising Fillets
|
型号 Type |
钢丝Wire |
针高A |
工作角X |
底布 |
针数 (25.4mm)2 |
日本金井型号 KANAI |
用途 |
||
|
号数 (CWG) |
线径 Dia.(mm) |
截面 |
宽 |
||||||
|
直脚起毛针布Raising(straight tooth) |
|||||||||
|
QS-1 |
29 |
0.380 |
|
10.4 |
80° |
23 |
260 |
与弯脚起毛针布配套用 |
|
|
QS-2 |
30 |
0.355 |
270 |
RT-30 |
|||||
|
QS-3 |
31 |
0.330 |
280 |
||||||
|
QS-4 |
32 |
0.305 |
290 |
RT-32 |
|||||
|
QS-5 |
33 |
0.280 |
300 |
||||||
|
QS-21 |
27×31 |
0.43×0.33 |
 |
25.1 |
40 |
240 |
刷绒针布 |
||
|
QS-22 |
27×31 |
0.43×0.33 |
28.2 |
82° |
300 |
RP-2 |
经编刷绒针布 |
||
|
起毛辅助针布(刷帚)Auxiliary card clothing for Raising
(Raising brush) |
|||||||||
|
QT-1 |
30 |
0.355 |
|
27.3 |
78° |
40 |
200 |
RB-30 |
织物起毛工艺辅助用 |
|
QT-2 |
31 |
0.330 |
230 |
RB-31 |
|||||
|
QT-3 |
32 |
0.305 |
260 |
RB-32 |
|||||
|
QT-4 |
33 |
0.280 |
290 |
RB-33 |
|||||
|
QT5 |
34 |
0.255 |
320 |
RB-34 |
|||||
